Blackmagic Design ATEM Micro Camera Panel

ATEM Micro Camera Panel portable camera panel with high end broadcast CCU controls, including battery, Bluetooth, and 8 camera select buttons for iris, pedestal, shutter, white balance, master gain, RGB balance and more. ATEM Micro Camera Panel is a portable camera panel with high end broadcast CCU controls. Control iris, pedestal, shutter, white balance, master gain, RGB balance and more for up to 8 cameras from a single panel. Connects to ATEM Software Control via Bluetooth or USB‑C.

Works with Blackmagic Studio,URSA Mini and Broadcast Cameras

ATEM Constellation works with the latest Blackmagic SDI cameras that have studio camera features that you can remotely control! This means you get remote camera control, tally indicators and a DaVinci color corrector built in. All control is via the switcher aux output connection to the camera PGM SDI input, allowing you to broadcast control commands from the switcher to the camera with a single SDI cable! That means you can remotely control settings in the camera plus focus, iris and zoom on supported lenses. Pocket Cinema Cameras include a DaVinci primary color corrector so you get more than simple CCU controls as you can also do a full color grade in the camera for a cinematic look!

Works seamlessly with all ATEM control panels!

Adding an ATEM Camera Control Panel to your ATEM Constellation is easy as all the network settings have been assigned for you, so you can simply connect direct from the ATEM Camera Control Panel to the switcher’s Ethernet connection. The ATEM panels feature loop through Ethernet connections so you just loop through the panels. Because Ethernet is a network, you can interconnect multiple ATEM Camera Control Panels with the ATEM Advanced Panels to complete a customized and professional broadcast production studio. On ATEM Micro Camera Panel, you connect via USB-C or Bluetooth. Plus, if you're doing location work, you can move the panels between any ATEM switcher model for different types of jobs.

ATEM Micro Camera Panel is a portable camera panel with high end broadcast CCU controls. Control iris, pedestal, shutter, white balance, master gain, RGB balance and more for up to 8 cameras from a single panel. Connects to ATEM Software Control via Bluetooth or USB‑C.

• ATEM Micro Camera Panel
• Welcome wallet with QR code for software download
• 1 x USB‑C cable

Product Specifics

Camera Selection buttons : 8 x NKK buttons. Assignable via setup utility.

Camera Number Display: Green off air, red on air.

Setup : White and black balance setup. Flare via modifier key.

3 Axis Joystick : 1

Preview Button : 1

Iris Control : Auto Iris On, Coarse control.

Iris Range : CLS f32 to f1.2

Gain Range :-12dB to +32dB

ND Filters : 0, 2, 4, 6.

Shutter Range :1/24 to 1/2000

White Balance Range : 2500K to 10,000K

Recallable Scenes : 5 per camera.

Panel Active : Protects settings.

Software

Software Applications :
ATEM Micro Panel controls ATEM Software Control Panel running on the host computer.
